Reactor Material of Construction in the Chemical Industry: Selection Process
Designing and scaling up a process plant is one of the most critical and complex responsibilities of a chemical engineer. One of the foundational decisions in this process is the selection of the Material of Construction (MOC) for key equipment—especially reactors, where chemical transformations take place. Whether you’re working with a small batch setup or planning a commercial-scale chemical process, the MOC, reactor type, and configuration directly impact safety, longevity, cost, and overall efficiency.
This article will explore the importance of MOC in reactor selection, the role of MOC during scale-up, comparisons between different materials like Stainless Steel, Mild Steel, Glass-Lined, and Specialty Alloys, MOC selection for utility versus process side, and real-world challenges in choosing the right material.
Table of Contents
Why MOC Selection Matters in Reactor Design
The reactor is the heart of any chemical process. Depending on what reactions take place, the materials used in construction must resist corrosion, pressure, temperature, and contamination. In the chemical industry, especially for corrosive or hazardous materials, selecting the wrong MOC can lead to equipment failure, frequent maintenance, product contamination, safety hazards, and unplanned shutdowns. Therefore, reactor MOC is not a decision to be made lightly or based solely on cost.
Challenges in Reactor MOC Selection During Scale-Up
When scaling up from lab to pilot or commercial production, reactor MOC selection becomes particularly challenging. For existing processes, engineers often duplicate specifications from similar installations or refer to plant standards, reducing risk. However, for a new process, there’s limited operational history. Making the wrong MOC decision at this stage can lead to serious operational and financial consequences. You must weigh chemical compatibility, thermal stability, mechanical strength, cost, and availability.
Overview of Common Reactor Materials
A wide variety of materials are available for constructing chemical reactors, each with its own advantages and limitations depending on the chemical media and operating conditions.
Stainless Steel Reactor (SS 304, SS 316, etc.)
Stainless steel is a popular choice for reactors due to its good corrosion resistance, mechanical strength, and availability. SS 304 is used for general purposes, while SS 316 or 316L is preferred in chloride-containing environments. It is suitable for many organic and inorganic processes and is generally considered a reliable, cost-effective solution for moderately corrosive conditions.
Mild Steel (MS)
Mild steel is commonly used for utility applications such as jackets, piping, cooling water lines, and compressed air systems. While it’s cost-effective, MS offers poor corrosion resistance for most chemical process fluids. As such, it is not suitable for the process side unless lined with protective coatings or used in non-corrosive environments.
MSGL Reactors (Mild Steel Glass-Lined)
These reactors combine the mechanical strength of mild steel with the corrosion resistance of glass lining. Ideal for corrosive processes at scale, especially when full stainless steel isn’t economically viable.
Glass-Lined Steel Reactors (SSGLR)
Glass-lined steel combines the mechanical strength of steel with the corrosion resistance of a borosilicate glass lining. These reactors are widely used in pharmaceutical, fine chemical, and agrochemical industries. They are ideal for acids, halogens, and solvents. However, they are not compatible with hydrofluoric acid, strong hot alkalis, or highly abrasive materials. Glass-lined reactors are available in large sizes (up to 25,000 gallons) and offer reliable performance under vacuum and elevated temperatures.
Borosilicate Glass Reactors (glass reactor)
These reactors offer excellent corrosion resistance, ideal surface cleanliness, and unmatched visibility. They are commonly used in labs and pilot plants. Their non-porous surface prevents contamination and allows for easy cleaning. They’re also chemically inert and don’t leach metal ions into the process stream. However, their size is limited (≤1000 mm diameter), and they are sensitive to mechanical and thermal shock.
Specialty Alloys (Hastelloy, Inconel, Titanium, Monel, Tantalum)
These are selected when conventional materials like stainless steel or glass-lining can’t withstand the chemical or thermal environment.
- Hastelloy C-276 is excellent for handling oxidizing and reducing chemicals.
- Inconel 600 is used in high-temperature applications and resists oxidation.
- Titanium provides high strength and excellent corrosion resistance, particularly in seawater or hypochlorite service.
- Tantalum resists even the most aggressive acids like nitric or sulfuric acid.
- Monel 400 performs well in saline and alkaline environments.
While these materials offer superior performance, they are significantly more expensive and often reserved for niche applications.
Plastics and FRP (PFA, PP, PTFE, TEFZEL)
Plastic-lined or fiberglass-reinforced plastic equipment is common in low-pressure, highly corrosive environments. These materials offer high resistance to acids, alkalis, and organic solvents but are not suitable for high temperatures or mechanical loads. They are often used in storage tanks, scrubbers, and transfer systems.
Glass and Glass-Lined Equipment: Pros and Cons
Advantages of Glass and Glass-Lined Reactors
- Corrosion Resistance: Ideal for halogens, acids, and organic chemicals.
- Smooth Surface: Anti-stick and easy to clean.
- Chemical Inertness: Prevents metal contamination or catalytic interference.
- Visual Monitoring: Borosilicate glass allows visibility; coated variants protect against light.
- Explosion Safety: Inert and approved for use in explosive atmospheres.
Limitations to Consider
- Chemical Compatibility: Not suitable for HF, concentrated hot caustics, or phosphoric acid.
- Mechanical Limitations: Sensitive to impact and sudden temperature changes.
- Size Constraints: Glass vessels are limited in scale; beyond that, glass-lined steel is used.
- Inspection Complexity: For glass-lined steel, wall thickness is harder to measure than with clear glass.
Utility vs. Process Side – Different MOC Requirements
Chemical engineers must distinguish between the process side (where the chemical reaction happens) and the utility side (where heating/cooling takes place). The MOC for these areas differs.
- Process Side: Requires corrosion resistance based on chemical compatibility. Stainless Steel, Glass-Lined Steel, or Special Alloys are preferred here.
- Utility Side: Typically handles water, steam, brine, or oil. Mild Steel is sufficient in most cases due to lower corrosion risks and cost advantages.
Always select utility side materials based on thermal fluid properties, pressures, and longevity requirements.
Key Selection Variables for Reactor MOC
When deciding the best MOC for your reactor and equipment, consider:
- Corrosion Resistance – Analyze feed, intermediates, and product chemistry.
- Operating Conditions – Include temperature, pressure, reaction time, and cleaning cycles.
- Cost and Budget – Capital cost vs. lifecycle cost should be balanced.
- Expected Life – Consider planned operating life and cleaning/maintenance frequency.
- Ease of Fabrication and Availability – Some materials require special welding and design know-how.
- Plant Standards and Existing Infrastructure – Matching current MOC can reduce complexity and inventory.
Typical Application Examples
- Organic acid synthesis: SS 316L or Glass-Lined
- Chlorinated solvent process: Glass-Lined or Hastelloy
- Sulfuric acid dilution: Tantalum or PTFE-Lined
- Caustic applications: FRP or PTFE
- Utility jackets: Mild Steel
Conclusion
Reactor material selection is not just a design decision—it’s an operational strategy. A good MOC choice ensures reliability, performance, and safety over decades of use. Stainless Steel remains the industry’s workhorse, while Glass-Lined and Special Alloys serve more aggressive chemical duties. For utility systems, Mild Steel can save significant cost when used appropriately.
In short: Choose process-side materials based on the process chemistry and utility-side materials based on thermal performance and service conditions. When in doubt, consult corrosion resistance charts, prior experience, and simulation data.
Need help selecting the right reactor MOC for your project?
Reach out for technical guidance on reactor design, scale-up strategy, and construction material selection.
